The GE-Emerson IC200MDL730 VersaMax Discrete ESCP Output Module includes electronic overcurrent protection and short circuit protection for each point, and generates a fault if either condition exists. The outputs are positive or sourcing type outputs. They switch the loads to the positive side of the DC supply and thus supply current to the loads.
An external DC power supply must be provided to switch power to the loads.
At powerup, the backplane power supply must be on and stable for 1sec before field power is applied to the module. Failure to follow this sequence could result in false output point faults. These faults can be cleared.
Intelligent processing for this module is performed by the CPU or NIU.
