Remanufactured Allen-Bradley 1746-OV8 SLC 500 DC Output Module

8 outputs in a single group, 24VDC voltage category.

Remanufactured

$100.00
Availability
  • 4 in stock

Repair

Call for pricing
Availability
  • Usually ships in 2-3 weeks
Part Number
  • 1746-OV8RMN
Manufactured
Product Specs

Features

  • 10 to 50VDC sink voltage range
  • 1 or 0.5 Amps current/output
  • 8 or 4 Amps current/module
  • 135mA @ 5V backplane current
  • Designed for high-density, low-current & high-current DC outputs
  • Step response:
    • In: 60ms
    • Out: 25ms
  • 5 to 95% relative humidity without condensation
  • Signal delay:
    • ON: 0.1ms
    • OFF: 1.0ms
  • UL/C-UL Listed Class I, Div 2, Groups A, B, C, D
  • CE marked for all applicable directives
  • C-Tick marked

The Allen-Bradley 1746-OV8 SLC 500 DC Output Module is a current sinking module designed for general use applications. It is equipped with color-coded terminal blocks, and can be wired with a pre-wire cable and a 1492 interface module. Self-lifting plates at the terminals can accept up to 14 AWG (2mm2) wires. LED indicators on the front panel display the I/O status.
